Yacht
By Russ, on September 2nd, 2006
Designer Frans Maas had the changeable North Sea weather in mind when he designed the Compromis 999 class. Particularly for longer trips in open water, this is a wonderfully strong and comfortable yacht. It is a Category-A Ocean class sailing sloop. “Enterprise” has the taller 12m mast and also an interesting Scheel keel which gives it a shallow draft of only 1.25m but no loss of stability or speed over the longer fin keel option.
“Enterprise” is also spacious giving me 6′ headroom and an aft cabin that, as a result of the centre cockpit design I can actually stand in the aft cabin rather than have to slide into a tube to lie down.
The other effect of the centre cockpit is that it is quite deep, and it is easy to brace yourself for those bracing two reef English Channel “cruises” !
Click to link to the Compromis and C-Yacht Club
Click here to connect to Compromis for sale
Below are links to a gallery of pictures…click on the photos
|
Sailing
|
External
|
Internal
|
 |
 |
 |
| Mech. & Electrical |
Nav Instruments Mech. & Electrical |
Hull |
|
|
|
|
Also videos on YouTube from other owners here and here
Enterprise
Technical Specification |
| Designer Constructor |
Frans Maas Zaadnoordijk Yachtbuilders, Heerenveen (NL) |
| Certification |
CE Category A (Ocean) ; wind > 8 Beaufort ;
wave height over 4 m |
| Length overall |
(LOA) 9.60 m |
| Waterline length |
(LWL) 8.15 m |
| Beam |
3.40 m |
| Draft Scheel Keel |
1.25 m |
| Displacement standard |
4 900 kg |
| Ballast standard |
2 000 kg |
| Air draft |
12.50 m |
| Mast length |
12.00 m |
| Mainsail standard |
19.20 m2 |
| Genoa standard |
22.40 m2 |
| Fresh water |
150 litres |
| Fuel |
70 litres |
| Waste water holding tank |
60 litres |
| Engine |
20.1 kW (27.3 HP) Yanmar Saildrive |
| Berths |
4 to 6 |
| Headroom in saloon |
1.96 m |
Deck/Hull/Steering
system
- Stainless steel pulpit and pushpit and double wire
quard rails
- Windscreen, aluminium alloy with security glass
- Mechanical wheel steering on Whitlock pedestal
- Halyards worked from cockpit with winches and
stoppers (2×3)
- ST sheetwinches, two speed
- Steering wheel covered with leather
- Non-skid material on deck
- Teak lining on cockpit sole and benches
- Gas spring for locker
- Lacquered entry hatch
- Double sliding hatch (one of plexiglass)
- Middlecleats
- Sheet traveller
- Stainless steel boarding ladder – flattened steps
- Bowroller, anchor well and 12kg Danforth anchor with
4 m chain and 30 m cable
- Separate well for two (dutch) gasbottle
- Cabinroof with non-skid material
- Stainless steel swan neck at mast heel for cables
- Antifouling
|
Ballast
/ keel
- Cast iron keel with a ballast of 2000 kg
- Draught 1,50 m (option Scheel Keel 1,25 m)
|
Sails
/ Mast
- De Vries sails mainsail 19,20 sqm with two reefs, 310
gr/sqm
- Seldon Mast of 10,60 m, clearance height 12,50 m
- Seldon Boom, 2 x single line reefing system, worked
from cockpit
- Seldon Rodkicker with gas spring
- Furlex roller reefing system 7 mm.
- Roller reefing genoa 22,4 sqm with shape tape, 310
gr/sqm
- Windex
- Sail cover
- Genoa cover
|
Interior
- Luxuriuosly upholstered cushions
- Teak cabin sole
- Curtains
- Sunscreens
- Cabin in teak lining
- Complete set of interior lights with switch-board and
automatic fuses
- Waste water tank ( 60 liter) for toilet with filter
- Coolingbox compressor/evaporator system
- Waterpressure system with 2 single lever taps,
pressure tank and carbon filter + extra footpump
- Freshwatertank150 liter with level indicator
- Stainless steel wash basin in WC compartment
- Flushing toilet
- Galley with stainless steel wash basin
- Semi-gimballed 3 burner hob with oven
- Waste bin
- Permanent chart table, lighted
|
Electrics
/ Motor / Instruments
- Yanmar Saildrive Diesel, 20,1 kW (27,3 HP) with
intercooling
- Strainer for cooling-water
- Stainless steel fuel tank, 70 liter with level
indicator
- 2 Storage batteries about 105 Ah with main-switches
and isolating diodes
- Shore connector 230 V with battery recharger 40 Amp
completely secured + CEE cable of 25 meter
- 16 A Earth leckage/fuses – automatic
- 230 volt connection in galley and at chart table
- Bilge pump mechanical
- Compass fitted on steering pedestal
- Complete set of navigationlights + anchor light
|
Safety
Equipment / Inventory
- Emergency tiller
- 2 Fire extinguishers
- Lightning conductor via main shrouds
- Lifebuoy with holder
- 8 Fenders
- 4 Mooring warps
- Boathhook
- Ensign with flagpole
|
|
Onthaal aan mijn website
|
Ontwerper Frans Maas had de wisselvalige Noord zee weer in gedachte toen hij de Compromis 999 classe ontworp. Voornamelijk voor langere reizen in open water is dit een aanzienlijk sterk en comfortabele yacht. Het is een Category-A Ocean class zeil sloop. “Enterprise” heeft de langere 12m mast en een bijzondere Scheel keel wat het een ondiepe voortgang van 1.25 meter levert maar geen verlies van stabiliteit of snelheid geeft tegenover de lange vin kiel optie.
“Enterprise” is ook ruim en geeft me een 6 hoofdruimte en een aft cabine dat, als resultaat van een centrale cabine ontwerp het mij mogelijk maakt recht op te kunnen staan in plaats van het inschuiven om te kunnen liggen.
Een ander effect van een center cockpit is dat het vrij diep is, en dat vergemakelijkt het gezelf vast te houden tijdens de Engels reef channel “cruises”
|
